REP PR-5000 Half Rack with Ares 2.0

$6,699.00$7,199.00

Size
Assembly

View delivery information

For courier service or free doorstep delivery, the point of delivery will only be up to your doorstep, with no stairs prior to that. If you require items to be carried up stairs of any sort, or require further shifting/ transporting/ removal, advance notice is required due to time constraints. Please note that additional fees will be collected. Service fee imposed will be based on the number of flights and the difficulty of the task. Click here for more information: FAQ

REP PR-5000 Half Rack with Ares 2.0 - 80" / Self Assembly is backordered and will ship as soon as it is back in stock.

Specifications

  • Pulley Ratio
    2:1 (100kg load : 50kg resistance)
  • Weight Stack
    2 x 118kg (260lb)
  • Adjustability
    27 adjustable cable position
  • Spotter Length
    74cm
  • Mainframe
    75x75mm, 11-gauge Steel
  • Material
    Steel
  • Storage Sleeve
    6 x 15.2cm, 4 x 30.5cm
  • Transport Wheels
    No
  • Extra Features
    Attachment included. Foot plate included. Selectorized hot-rolled steel weights. Lat pull and seated row function. Aluminum Pulleys. 180 degree swivel cable system.
  • Installation
    Not included. Please refer to the option for assembly service.
  • Dimensions
    80inch: 130 (L) x 191 (W) x 208.5 (H) cm / 93inch: 130 (L) x 191 (W) x 238.5 (H) cm
  • Product Weight
    437.7kg (965lb)
  • Max Load
    RACK: 453.5kg (1000lb), CABLE: 204kg (450lb)
  • Hole Size
    25mm (1in)
  • Hole Spacing
    50mm (2in)
  • Surface Coat
    Metallic black powder coat
  • Warranty for Home
    Strength premium: Lifetime on structural frame (excludes coating & rust), 2 years on moving frames & components (bearings, lock pins, pulleys, cables, glide rods etc), 1 year on labour. Wear & tear exclusion.

Description

The REP PR-5000 Half Rack offers the same commercial-grade quality and modular compatibility as the Power Rack, in a more compact, open-front design—ideal for those seeking a space-efficient training setup. Built from 75x75mm 11-gauge steel, it also supports a rackable weight capacity of 453.5 kg (1,000 lbs). Featuring 2-inch hole spacing, 1-inch pinholes, and laser-cut numbering, it allows for highly accurate attachment placement and quick adjustments. Storage is streamlined with six 15cm top weight horns for smaller plates and four 30cm horns at knee level for heavier ones.

Included are Lowered J-Cups 2.0 with recessed linings to protect equipment and optimize bar placement. The 59.5cm gusseted front spotter arms provide strong external safety support, featuring raised lips to prevent barbell roll-off. Additionally, a 66.3cm front foot extension stabilizes the rack when training outside the uprights. Precision manufacturing techniques such as laser cutting, robotic welding, and premium powder coating ensure this rack stands out as a centerpiece in any home gym.

The Ares 2.0 is a high-performance functional trainer and lat pulldown/low row attachment system, designed to integrate seamlessly with the PR-5000 rack. Developed from customer feedback and REP’s innovation-driven approach, the Ares 2.0 combines versatility, efficiency, and commercial-grade quality into one compact solution. At its core are dual 118 kg (260 lb) selectorized weight stacks, supporting both unilateral and bilateral training. A 2:1 cable ratio (e.g., 100 kg load = 50 kg resistance) offers precise resistance adjustments, ideal for functional and accessory training.

This system is outfitted with swivel pulleys at each front upright, typically found in high-end commercial equipment, allowing a greater range of motion and smoother movement. The pulleys have been repositioned to the outer edges of the trolley to improve ergonomics, while the cables are routed from below, enabling the trolleys to rest at the base and clear space on the uprights for other attachments. Each trolley includes a smooth plastic liner for fast and easy adjustment. Upgraded cables with a thinner coating deliver a smoother, more refined user experience, while hot-rolled steel weight plates with a machined finish ensure long-term durability and performance. The independent stacks allow two athletes to train simultaneously or one athlete to use both stacks in a variety of exercises.

The Ares 2.0 also features an integrated lat pulldown and low row station, complete with an improved footplate design that provides enhanced comfort and better starting angles. The weight stacks are rotated 90 degrees and set farther back within the rack frame, creating additional space inside for benching and specialty barbell work.


REP PR-5000 Half Rack with Ares 2.0 Attachment includes:

● 1 x Lat pulldown bar
● 1 x Foot plate
● 2 x Carabiner clips
● 4 x Fully knurled D-handle attachments
● 2 x Integrated drop-down 5lb add-on weights
● 2 x Lowered 2.0 J-hooks
● 2 x Front foot extension
● 2 x Spotter arms
